Catalog No. PM2664
Color Red
Compositions K2SiF6: Mn4+
Particle Size 21, 24, 30 (D50/μm)

KSF Phosphor Powder is a kind of red powder with a composition of K2SiF6: Mn4+. Stanford Chemicals Company (SCC) offers high-quality KSF Phosphor Powder with competitive pricing.

Other related products: Green Silicate PhosphorsRed Nitride Phosphor Powder (YG630), Yttrium Gallium Aluminum Garnet (YGaAG) Phosphor Powder

Description

Description

KSF Phosphor Powder Description

KSF phosphor powder, a narrow-band red emission powder, is mainly applied to packing high-color gamut liquid crystal backlights and high-color rendering white LEDs. High light efficiency and high color purity are guaranteed with unique crystal synthesis technology for this product, ensuring good anti-deterioration performance.

Our LED phosphors provide an avenue for LCD manufacturers to offer products with high color gamut, which gives never-before color realism to the screen, with matching materials that fit high-performance color filters. This kind of LED phosphor material range shows outstanding stability and efficiency. Applied in red LED packages alone or combined with other yellow or green phosphors, this series of phosphors can package warm white or special light LEDs.

KSF Phosphor Powder

KSF Phosphor Powder Specification

Category

Product Name Specifications of Product
Relative Brightness Chromaticity Coordinates Chromaticity Coordinates Peak Wavelength Particle Size
(D50/μm)
FWHM
(nm)
Fluoride Phosphor

ZYPF631S

115-125 0.629±0.003 0.307±0.003 631±2 21±2.5 9
ZYPF631M 115-125 0.629±0.003 0.307±0.003 631±2 24±2.5

9

ZYPF631B 115-125 0.629±0.003 0.307±0.003 631±2 30±2.5

9

KSF Phosphor Powder Applications

– Human lighting – lighting that meets the needs of human natural clocks
– General lighting – such as retail, residential and professional lighting
– Backlighting – for smartphones, monitors, televisions, etc.
– Internal and external applications in the automotive industry

KSF Phosphor Powder Packaging

Our KSF Phosphor Powder is carefully handled during storage and transportation to preserve the quality of our product in its original condition.
