PM2848 Red Nitride Phosphor Powder (YG625)
Catalog No. | PM2848 |
Appearance | Red Orange Powder |
Red Nitride Phosphor Powder (YG625) is characterized by chemical stability, thermostability and high durability. SAM is your one-stop platform to find LED phosphor for sale in a variety of forms, who makes it easy for you to buy high-quality Red Nitride Phosphor Powder.
Related Products: KSF Phosphor Powder, Red Nitride Phosphor Powder (YG612), Red Nitride Phosphor Powder (YG615)
- Description
Description
Red Nitride Phosphor Powder (YG625) Description
A phosphor, most generally, is a substance that exhibits the phenomenon of luminescence; it emits light when exposed to some type of radiant energy. Red Nitride Phosphor Powder (YG625) is characterized by chemical stability, thermostability and high durability. It is non-poisonous, non-radioactive and non-corrosive.
As a one-stop platform for those to find LED phosphor for sale in a variety of forms, Stanford Chemicals Company (SCC) makes it easy for you to buy high-quality Red Nitride Phosphor Powder (YG625).
Red Nitride Phosphor Powder (YG625) Specifications
Product Name | Red Nitride Phosphor Powder (YG625) |
Emission Color | Red |
Relative Intensity | 100±2% |
Peak Wavelength (nm) | 625±1 |
CIE-X | 0.653±0.002 |
CIE-Y | 0.340±0.002 |
Density (g/cm3) | 3.6 |
Particle Size (μm) | 10±1.0, 5±1.0 |
Excitation range (nm) | 350-550 |
Red Nitride Phosphor Powder (YG625) Applications
Phosphor layers provide most of the light produced by fluorescent lamps, and are also used to improve the balance of light produced by metal halide lamps. Various neon signs use phosphor layers to produce different colors of light. Electroluminescent displays found, for example, in aircraft instrument panels, use a phosphor layer to produce glare-free illumination or as numeric and graphic display devices. White LED lamps consist of a blue or ultra-violet emitter with a phosphor coating that emits at longer wavelengths, giving a full spectrum of visible light.
Paired with other phosphor powder such as yellow silicate phosphor powder, Red Nitride Phosphor Powder (YG625) can be used to fabricate LED light with high color rendering and low color temperature.
