PM2847 Red Nitride Phosphor Powder (YG615)

Get A Quote






  I would like to join the mailing list to receive updates from Stanford Chemicals.
*: e-mail address with your company's domain name is preferred. Otherwise, we may not be able to process your inquiry.

Catalog No. PM2847
Appearance Red Orange Powder
Density 3.1 g/cm3
Particle Size 13±2.0 μm

Red Nitride Phosphor Powder (YG615) is characterized by chemical stability, thermostability, and high durability. SAM is your one-stop platform to find LED phosphor for sale in a variety of forms. We make it easy for you to buy high-quality Red Nitride Phosphor Powder.

Related Products: Yttrium Gallium Aluminum Garnet (YGaAG) Phosphor PowderKSF Phosphor Powder, Red Nitride Phosphor Powder (YG612)

Description

Description

Red Nitride Phosphor Powder (YG615) Description

A phosphor is generally a material that exhibits a phenomenon of luminescence; light is emitted as a result of exposure to some type of radiant energy. Red Nitride Phosphor Powder (YG615) has chemical stability, thermostability, and high durability; it is non-poisonous, non-radioactive, and non-corrosive.

Stanford Chemicals Company (SCC) is your one-stop platform to find LED phosphor for sale in a variety of forms and has over two decades of experience in the manufacture and sale of high-quality Red Nitride Phosphor Powder (YG615).

Red Nitride Phosphor Powder (YG615) Specifications

Product Name Red Nitride Phosphor Powder (YG615)
Emission Color Red
Relative Intensity 100±2%
Peak Wavelength (nm) 615±1
CIE-X 0.629±0.002
CIE-Y 0.371±0.002
Density (g/cm3) 3.1
Particle Size (μm) 13±2.0
Chip Size (nm) 445-470

Red Nitride Phosphor Powder (YG615) Application

The phosphor layers produce most of the light produced by fluorescent lamps and are further used to enhance the balance of light produced by metal halide lamps. A wide range of neon signs relies on phosphor layers to create different colors of light. A phosphor layer is used in electroluminescent displays for glare-free illumination or numeric and graphic display devices found in aircraft instrument panels. Therefore, white LED lamps can be fabricated using a blue or ultra-violet emitter coated with a phosphor that emits at longer wavelengths, ensuring that the devices give off a full spectrum of visible light.

Paired with yellow phosphor powder, Red Nitride Phosphor Powder, YG615 can be used to create LED light of high CRI. In general, Red Nitride Phosphor Powder, YG615 is applied for warm white LED light.
